This page describes the tasks completed by the team every week over the course of the project.

Project Plan



Figure 1: Gantt Chart of Project Timeline

Week 1

Objective

Background Research

Individual Tasks

Becky

  • ECG and set up iGEM wiki page

Calista

  • Cardiorespiratory monitors (features, functions and relationship with patient state)

Choi Wan

  • Physiological Systems

Eva

  • Heart rate variability (HRV) and slide template/design

Tara

  • Cardiorespiratory monitoring (who, what, where, why and how)

Presentation

Media: HRV_Background_1.pdf

Week 2

Objective

Research on currently available cardiorespiratory monitors and compare them

Individual tasks (companies to research on)

Becky

  • Omron and Getinge

Calista

  • Abbott, GE Healthcare and Medtronic

Choi Wan

  • Hill-Rom, Philips Healthcare and Boston Scientific

Eva

  • W.L.Gore & Associates and Lepu Medical Technology

Tara

  • Terumo and Edwards Lifesciences

Presentation

Media:HRV_CardioMonitors_2.pdf

Weeks 3-4

Objectives

  • Research into more specific aspects of cardiorespiratory monitors and compare them
  • Research from the perspective of clinicians

Individual Tasks

Becky

  • Home base of companies
  • Target users for each device
  • User interface for patients and HCP
  • Color code standard of alerts, interface, etc.
  • FDA and CE Mark classification, minimum requirements, testing criteria and approval

Calista

  • Cardiorespiratory parameters used for monitoring in the ITU and in relation to Covid
  • Real-life examples of cardiorespiratory monitoring in healthy and ill individuals
  • Siemens and their devices/technology
  • Strengths and weaknesses of each device (comparison)
  • Exercise monitoring (Omron, Apple Watch, Samsung) compared to clinical monitoring (accuracy standard)
  • Collaboration between clinicians and designers for product design

Choi Wan

  • Relationship and dependence between different parameters
  • Viewing mode of parameters in different devices (as graphs or values)
  • Criteria, differences between home monitoring or ICU monitoring
  • Market size and share of each major company
  • Invasive/non-invasive monitoring
  • Electronic patient records and their integration into hospitals/clinics

Tara

  • Cardiovascular conditions which are important to clinicians in the ICU
  • Perspective of clinician in selecting cardiorespiratory monitors
  • Minimal requirements of cardiorespiratory monitors in the ICU
  • Alarm systems in cardiorespiratory monitors

Eva

  • Off due to personal circumstances.

Presentation- Weeks 3&4

Media: HRV Clinician POV 3.pdf

Week 5

Objectives

  • Focus in on a few clinical conditions (COPD, heart attacks and sepsis)
    • What parameters are monitored and the clinical care pathways in hospitals for these conditions

Individual Tasks

Becky

  • Heart attack

Calista

  • COPD
  • Covid-19

Choi Wan

  • Sepsis

Eva

  • Sepsis

Tara

  • COPD

Presentation

Media: HRV_Conditions_in_ICU.pdf

Weeks 6-7

Objectives

  • Organise research into a clear structure on the Wiki
  • Integrate and connect the concepts and information gathered from previous weeks
  • Look at care pathways and case studies from journals

Individual Tasks

Update each section of the wiki with research from individual reports

Weeks 8-12

Objectives

  • Write individual reports and group planning report, first draft due by 28 Dec

Individual tasks

Becky

  • Report topic: Challenges of monitoring in the ICU
  • Group report section: Background, Preliminary Findings

Calista

  • Report topic: ECG
  • Group report section: Background, implementation plan/Gantt Chart

Choi Wan

  • Report topic: Sepsis
  • Group report section: Introduction, Background

Eva

  • Report topic: HRV
  • Group report section: Background, Conclusion

Tara

  • Report topic: COPD
  • Group report section: Backgorund, Risk assessment

Autumn Term Task Allocation


Figure 2: Autumn Term Task Allocations

Week 13

Objectives

  • Signal processing methodologies/code
  • Find ECG datasets to analyse
  • Continue documenting on new findings

Tasks

  • Learn basic python and github to code collaboratively
  • Search for clean ECG data (not waveforms) to open using code
  • Update the wiki with new findings

Week 14

Objectives

  • SWOT analysis on HRV calculation methods
  • Signal Processing of ECGs (e.g. Finding RR peaks)

Tasks

  • Read papers on HRV analysis in different domains and compare them
  • Learn more about pandas for ECG signal processing and using stream for large datasets
  • Study and understand (existing) code(s) for HRV analysis
  • Note the sampling rate for each dataset and extract 15-20 beats for processing

Presentation

Media:Different_methods_to_extract_HRV.pdf

Week 15

Objectives

  • Signal Processing of ECGs
  • Pipeline of HRV derivation from ECGs
  • HRV in a clinical setting

Individual Tasks

Becky

  • Reading ECG from .dat files
  • Plotting ECGs
  • Summarise and create a flowchart of different ECG signal processing steps

Calista

  • Filtering and removing baseline drift from ECGs (preprocessing)

Choi Wan

  • Reading ECG from .dat files
  • Derivative approach

Eva

  • Contacting clinicians to conduct interview/survey on the use of HRV in clinical settings
  • Read papers on HRV analysis

Tara

  • Finding R peaks from ECG

Presentation

Media:ClinciansUse.pdf

Week 16

Objectives

  • Create a general code which can process ECGs in a standardised manner (e.g. use the same sampling frequency, interpolation, etc.)
  • R peak detection code
  • Utilising different filters for preprocessing of ECGs

Individual Tasks

Becky

  • Create artificial ECG/add noise to create new samples for testing
  • Create a diagram to outline all the steps involved in signal processing

Calista

  • Apply different filters to ECG
  • Test filters with noisier data

Choi Wan

  • Develop original R peak detection code instead of using available python modules

Eva

  • Continue looking at papers about HRV from a clincian's perspective
  • Follow-up on clinicians about questions/survey
  • Look at what the different bands in the power spectral density graph mean how the power spectral density relates to actual long-term conditions

Tara

  • Resample the function at 1000Hz
  • Look at how smooth interpolation function works

Presentation

The following contains feedback and results from a survey of healthcare professionals including doctors and nurses and an interview with a general practitioner. Media: ClinicianSurveyResults.pdf

Week 17

Objectives

  • Develop signal processing code of ECGs
  • Pipeline of HRV derivation from ECGs
  • Research more into HRV in a clinical setting

Individual Tasks

Becky

  • Reading ECG from .dat files
  • Plotting ECGs
  • Summarise and create a flowchart of different ECG signal processing steps

Calista

  • Filtering and removing baseline drift from ECGs (preprocessing)

Choi Wan

  • Reading ECG from .dat files
  • Derivative approach for peak detection

Eva

  • Contacting clinicians to conduct interview/survey on the use of HRV in clinical settings
  • Read papers on HRV analysis

Tara

  • Finding R peaks from ECG

Week 18

Objectives

  • Create a general code which can process ECGs in a standardised manner (e.g. use the same sampling frequency, interpolation, etc.)
  • R peak detection code
  • Utilising different filters for preprocessing of ECGs

Tasks

Becky

  • Create artificial ECG with baseline drift and 50Hz noise
  • Add noise to normal sinus rhythm ECG to create new samples for testing

Calista

  • Research types of noise commonly found in ECGs
  • Apply different filters to ECG for denoising

Choi Wan

  • R peak detection using derivative approach

Eva

  • Continue looking at papers about HRV from a clinician's perspective
  • Follow-up on clinicians about questions/survey
  • Look at what the different bands in the power spectral density graph mean how the power spectral density relates to actual long-term conditions

Tara

  • Resample the function at 1000Hz
  • Look at how smooth interpolation function works

Week 19

Objectives

  • Organise code, put different sections of code together
  • Presentation on clinician survey results
  • Start group report

Individual Tasks

Becky

  • Combine all sections of code into main python script
  • Organise git repo

Calista

  • Improve filtering
  • Organise git repo

Choi Wan

  • Improve R peak detection
  • Organise git repo

Eva

  • Summarise and present data from survey
  • Find out more about Kubios (leading HRV analysis software in the market)

Tara

  • Improve pre-processing
  • Make a rough outline of group report

Week 20

Objectives

  • Standardising plots (axes, labels, units, etc.) for displaying results
  • Run the code on ECGs of different conditions and artificial ECG
  • Group report

Individual Tasks

Becky

  • Standardise plot function in main script
  • Test code with artificial ECG
  • Writing first draft of group report
  • Organise git repo

Calista

  • Fix errors with filter
  • Writing first draft of group report
  • Organise git repo

Choi Wan

  • Plot RR intervals on a single graph
  • Writing first draft of group report
  • Organise git repo

Eva

  • In-depth analysis and graphs of survey results
  • Present data from GP survey
  • Writing first draft of group report

Tara

  • Organise git repo
  • Writing first draft of group report

Week 21

Objectives

  • Fine-tuning code
  • Finalise group report for submission

Tasks

  • Edit group report draft based on feedback
  • Add all data to appendices and make it neat
  • Fix references

Spring Term Task Allocation

Group Member Responsibilities
Tarane Subramaniam
  • Research into the physiological conditions most important in ICUs.
  • Research on ARDS and relation to HRV.
  • Taking minutes during meetings.
  • Writing the Input module of code.
    • Eva Tadros
  • Research into HRV.
  • Acting team leader.
  • Research into spectral analysis and correlating frequencies to clinical conditions.
  • Contacting and reviewing feedback on HRV from doctors, nurses and other health care providers.
    • Rebecca Vickery
  • Creating and updating the wiki.
  • Research into problems faced by clinicians associated with monitors.
  • Writing the Artificial ECG module of the code.
  • Streamlining the whole HRV code so module inputs and outputs flow.
    • Calista Yapeter
  • Research into the functions and use of cardiorespiratory monitoring in the ICU, the ECG, and its relationship to HRV.
  • Updating the wiki journal.
  • Writing the Filter ECG module of the code.
    • Choi Wan Yip
  • Research on interdependence of physiological parameter.
  • Research on sepsis and relation to HRV.
  • Communications between the team and supervisors outside of meetings.
  • Writing the Peak Detection module and the RR interval section of code.
    • Table 2: Individual tasks assigned during the spring term.


    Tasks shared among all members:

    • Researching and comparing cardiorespiratory monitors from different companies
    • Researching the extraction of HRV in different domains

    Weeks 22 - 30

    Easter Break and Final Exams

    Week 31

    Objectives

    • Review feedback from group report
    • Poster design and content

    Individual Tasks

    Becky

    • Methodology section of poster

    Calista

    • Conclusion section of poster

    Choi Wan

    • Results section of poster

    Eva

    • Individual presentation

    Tara

    • Introduction section of poster

    Week 32

    Objectives

    Poster presentation
