OUR TEAM Error creating thumbnail: File missing Name: Arianna Moreno Error creating thumbnail: File missing Name: Pritish Char Error creating thumbnail: File missing Name: Chris Joseph Ibarra Error creating thumbnail: File missing Name: Jared Smith Error creating thumbnail: File missing Name: Almoustafa Abbas LAB 5 WRITE-UP Background Information SYBR Green Dye SYBR green; nucleic acis gel, is one of the most sensetive stains available for detecting double stranded DNA in agarose and polyacrylamide gels. because of its senseitivity, it is very useful for assays where the presence of contaminating RNA or ssDNA might obscure results. its easy to use as gels soaked in diluted stain can be visualized without desalting. it is detectable with UV lights, gel documentation systems and laser scanners. Severa other features make SYBR Green particularly useful as a nucleic acid stain. It is known to be stable over a range of temperatures, which means that it can be used to monitor biochemical reactions that take place at high and low temperatures. It bind non covelantly to the surface of the DNA, meaning that it will not interfere with the activity of most nucleases and DNA polymerases. It also binds to nucleic acids over a dynamic linear range of up to four orders of magnitude, giving an accurate quantification of DNA over a wide range of concentrations. Single-Drop Fluorimeter fluorimeter is a fluroscence parameter messurment device. its intensity and wavelength distribution of emission spectrum after excitation by a certain spectrum of light. these parameters are used to identify . these parameter are used to identify the presence and the amount of a certain molucule in the medium. they can detect dlurocent molcule concetration up to 1 ppt ( part per trillion) . The design of any typical fluorometer has several key components. It has an input source for ordinary visible light, and this light is passed through an excitation filter that allows only specific wavelengths of it to impact onto a sample cell of the material being studied. When this material, whether organic or inorganic, is bombarded by these controlled wavelengths of light, it fluoresces, emitting characteristic light of its own that is then passed through an emission filter. The emissions are read by a light detector which produces a readout for the observer to know how the sample is reacting and what its contents are. Error creating thumbnail: File missing - Fluorimeter Set-Up How the Fluorescence Technique Works Fluorescence is a very sensitive detection technique. A beam of light shines through the drop at a certain wavelength and excites the electrons in molecules of the drop causing it to emit a light of a longer wavelength. The slide we are using is coated with a rough layer of Teflon but has circles of bare glass. This combination of properties results in a superhydrophobic surface that allows the solution to cling to the glass but repel from the layer of Teflon. The environment from the slide allows the blue LED light to focus on the drop and thus increases the intensity of the fluorescence event. The combination of the SYBR Green Dye I and the solution form a complex with the DNA that prefers to go to the surface creating the beach ball shaped drop on the slide. This specific material creates the perfect environment to then measure the fluorescence of the sample. In this particular experiment, we use ImageJ software to measure and analyze the degree at which the fluorescence is emitted from the sample to understand the components of the DNA sample. Procedure Smart Phone Camera Settings Type of Smartphone: iPhone 4s Flash: Off ISO setting: Auto White Balance: Auto Exposure: Auto Saturation: Auto Contrast: Auto Calibration Turn the fluorimiter light on. Adjust the camera's settings to match the above. Place the phone on the cradle or stand at a right angle from the slide, perpendicular to the surface. Adjust the height of the fluorimeter using the plastic trays so that the camera picture has a clear view of the side of the drop. Error creating thumbnail: File missingError creating thumbnail: File missing The set up of the fluorimeter should look similar to shown(right image) and when looking through the phone's camera screen, it should appear similar to shown (left image). Distance between the smart phone cradle and drop = 8cm Solutions Used for Calibration Concentration of Calf Thymus DNA (µg/mL) Volume of DNA Solution (µL) Volume of SYBR Green I Dye Solution (µL) Final Concentration of DNA in solution (µg/mL) 5 80 80 2.5 2 80 80 1 1 80 80 0.5 0.5 80 80 0.25 0.25 80 80 0.125 0 80 80 0 Placing Samples onto the Fluorimeter 1. Insert the slide into the fluorimiter with the smooth, glass side down. 2. Get a 80 microliter measurement of the SYBR Green I and place this drop in the middle of the first two rows of the slide. The drop should look like a ball on top of the slide. 3. Get a 80 microliter measurement of the calf thymus solutions and place this solution on top of the SYBR Green I. 4. Align the slide so that the blue LED light is focused by the drop to the middle of the black fiber optic fitting on the other side of the drop. 5. Set the camera timer, then put the light box over the whole setup. Data Analysis Representative Images of Samples No DNA: DNA: Image J Values for All Samples Final DNA concentration in SYBR Green I solution (µg/mL) AREA Mean Pixel Value RAWINTDEN OF THE DROP RAWINTDEN OF THE BACKGROUND DROP-BACKGROUND 2.5 47600 175.604 8358740 192210 8166530 2.5 49624 173.63 8616223 209182 8407041 2.5 49624 176217 8744600 211479 8533121 1 49624 117.528 5832208 188774 5643434 1 49624 118.981 5904302 190959 5713343 1 49624 113.687 5641590 188851 5452739 0.5 49624 80.465 3992971 181507 3811464 0.5 49624 78.058 3873566 185690 3687876 0.5 49624 78.988 3919689 184420 3735269 0.25 49624 81.546 4046657 162423 3884234 0.25 49624 82.679 4102843 168964 3933879 0.25 49624 90.321 4482073 167377 4314696 0.125 49624 20.713 1027841 165444 862397 0.125 49624 21.425 1063195 163794 899401 0.125 49624 20.658 1025137 162862 862275 0 49624 7.155 355061 158941 196120 0 49624 6.243 309800 161363 148437 0 49624 6.479 321531 166295 155236 Fitting a Straight Line PCR Results Summary Instructor's summary: You completed 8 PCR reactions in a previous lab. You used the SYBR Green I staining and imaging technique to measure the amount of amplified DNA in each PCR reaction. You used a standard curve (based on known concentrations of calf thymus DNA) to convert INTDEN values into DNA concentration. Your positive control and negative control samples should be used as threshold values for determining whether an unknown (patient) sample is truly positive or negative. Your positive control PCR result was 0.274126694 μg/mL Your negative control PCR result was -0.041063194 μg/mL Write-in each patient ID and give both a qualitative (what the images looked like) and a quantitative description (μg/mL) of what you observed Patient 43849: None of the images contained any fluorescence. The samples for this patient had an average corrected concentration of -0.05994057 μg/mL Patient 80853: All of the images contained fluorescence. The samples for this patient had an average corrected concentration of 0.293841144 μg/mL Compare each patient's results to the positive control value and the negative control value. Draw a final conclusion for each patient (positive or negative) and explain why you made that conclusion. Patient 43849: Because none of the images contained fluorescence and the samples came back negative, this patient must be the negative one. Patient 80853: Because all of the images contained fluorescence and the samples came back positive, this patient must be the positive one.
