The CHA reaction described in the introduction allows for the detection of oligonucleotides. The oligo detected is C1, Figure 8A. C1 has 3 domains: the toehold binding domain (1*) and the domains that undergo branch migration in order to open H1. However, previous work has shown that these catalytic domains do not have to be found on a single oligo. These domains can be split between separate oligos and still trigger CHA when colocalized on a common template, Figure 8B. This modified variant of CHA will be referred to as split catalyst CHA (scCHA) in this work.

Figure 8: In scCHA the catalytic domains of C1 are split between two oligos that anneal to a common template. A: One oligo, mTH, contains the toehold binding domain. The branch migration domains are found on a separate oligo, mBM. These two oligos are brought together by the organizing strand, mOS, to form the catalytic assembly product, AP.
Figure 8: In scCHA the catalytic domains of C1 are split between two oligos that anneal to a common template. A: One oligo, mTH, contains the toehold binding domain. The branch migration domains are found on a separate oligo, mBM. These two oligos are brought together by the organizing strand, mOS, to form the catalytic assembly product, AP.

Further Modifications of the Catalyst

The scCHA catalyst can be further modified in order to detect minor structural defects in mOS. By including limited complementarity, 1-2 bp, between the 1 domain of mTH and mOS, the rate of catalysis can be greatly reduced, Figure 9. When the 1 domain is partially annealed to mOS it is hindered from annealing to the toehold on H1. However, if a defect is present in mOS in this region of complementarity, the 1 domain will be freed to function normally and the rate of catalysis is restored. For our purposes this defect can be an SNP allele or an AP site. mOS is the target sequence to be detected and characterized by our circuit.

Figure 9: Limited complementarity between the 1 domain and mOS allow for detection of defects within mOS.
Figure 9: Limited complementarity between the 1 domain and mOS allow for detection of defects within mOS.

MDM2 Circuit Design

In order to have a circuit that would specifically detect and characterize SNP309 of the MDM2 gene, new CHA circuit pieces were designed using CircDesigNA. Hairpins were designed to not interact with the MDM2 gene in the absence of the split catalyst pieces, Table 1. The split catalyst was designed as depicted in Figure 10. The MDM2 gene sequence determined a majority of the split catalyst sequences and the remaining sequences were designed by CircDesigNA.

Figure 10: The MDM2 SNP is our detection target and acts as an mOS for the purposes of scCHA. The catalyst piece containing the 1 domain (red) is complementary to the region of the MDM2 gene upstream of SNP309, p0. This complementarity continues into the first two bases of 1. The catalyst piece with the 2 and 3 domains contain a region that is complementary to the region downstream of SNP309. These complementary regions bring both catalyst pieces together for CHA triggering.
Figure 10: The MDM2 SNP is our detection target and acts as an mOS for the purposes of scCHA. The catalyst piece containing the 1 domain (red) is complementary to the region of the MDM2 gene upstream of SNP309, p0. This complementarity continues into the first two bases of 1. The catalyst piece with the 2 and 3 domains contain a region that is complementary to the region downstream of SNP309. These complementary regions bring both catalyst pieces together for CHA triggering.
Table 1: The sequences of the MDM2 and AP site circuits are given below. The p1 designation is used to indicate the last base of complementarity between the Cat_1p1 pieces and the target sequence template.
Oligo Name Description Sequence (5' to 3')
MDM2
BioM_MDM2_Cat_1,2,3p1 Continuous catalyst for testing circuit hairpins CTTCAAACCCTAAATCGACACAAC
BioM_MDM2_Cat_1p1 Split catalyst piece containing domain 1 CACCTGCGATCATCCGGACCTCCCGCGCCGACACAAC
BioM_MDM2_Cat_2,3p1 Split catalyst piece containing domains 2 and 3 CTTCAAACCCTAAATCGCGGCCCCGCAGCCCCCGGCCCCCGTGAC
BioM_MDM2_H1p1 Hairpin 1 for MDM2 detection and characterization GTTGTGTCGATTTAGGGTTTGAAGCTCTCTCCCTTCAAACCCTAAATCCCTCCCTCCCTCCCTC
BioM_MDM2_H2p1 Hairpin 2 for MDM2 detection and characterization GTTTGAAGGGAGAGAGCTTCAAACCCTAAATCCTCTCTCC
BioM_MDM2_RepFp1 Flurophore tagged reporter oligo for MDM2 detection and characterization /56-FAM/GAGGGAGGGAGGGAGGGATTTAGG
BioM_MDM2_RepQp1 Quencher tagged reporter oligo for MDM2 detection and characterization CCTCCCTCCCTCCCTC/3IABkFQ/
Apurinic Site
BioM_Cat_1,2,3p1 Continuous catalyst for testing circuit hairpins CTTTTCTGCATCTATCTCCTAACC
BioM_Cat_1p1 Split catalyst piece containing domain 1 GAACCCCCGGTTCCTCTCCTAACC
BioM_Cat_2,3p1 Split catalyst piece containing domains 2 and 3 CTTTTCTGCATCTATCGTACTGAGGGGGCGTA
BioM_H1p1 Hairpin 1 for AP site detection and characterization GGTTAGGAGATAGATGCAGAAAAGCAATTGTCCTTTTCTGCATCTATCGAAGTAAGGTAGTGTG
BioM_H2p1 Hairpin 2 for AP site detection and characterization CAGAAAAGGACAATTGCTTTTCTGCATCTATCCAATTGTC
BioM_RepFp1 Flurophore tagged reporter oligo for AP site detection and characterization /56-FAM/GTAGTGTGGAAGTAAGGATAGATG
BioM_RepQp1 Quencher tagged reporter oligo for AP site detection and characterization CTTACTTCCACACTAC/3IABkFQ/

Apurinic Circuit Design

The apurinic circuit was designed in the same fashion as the MDM2 circuit. The catalyst pieces were designed to assemble on the A4324 loop of the 28S rRNA, Figure 11. The remaining circuit pieces for the apurinic design can be found in Table 1.

Figure 11: The catalyst pieces assemble on the A4234 loop of the 28S rRNA such that the A4324 ( p0) is the complement of the first base of domain 1.
Figure 11: The catalyst pieces assemble on the A4234 loop of the 28S rRNA such that the A4324 ( p0) is the complement of the first base of domain 1.
