Insert datasheets or representative experiments in this page.
File:F2620absrel.png Steady-state characterization in microplate reader of BBa_F2620 in absolute and relative units in the MG1655 strain, M9 suppl medium (Zucca et al., BMC Bioinformatics, 2012) |
File:ConstRPUplos.png Steady-state characterization in microplate reader for 5 promoters via 3 different reporter systems: BBa_E0240 (GFP32), BBa_I13507 (RFP34) and BBa_K516032 (RFP32), all in pSB4C5 in the TOP10 (Invitrogen) strain. Upper panel: M9 suppl medium, lower panel: LB medium. PLlacO1 is induced with 1mM IPTG (Pasotti et al., PLoS ONE, 2012) | |
File:ConstRPUlow.png Steady-state characterization in microplate reader for 8 promoters via the BBa_I13507 (RFP34) reporter system in pSB4C5 in the KRX (Promega) strain, M9 suppl medium (Pasotti et al., PLoS ONE, 2012) |
