This special page shows all uploaded files.
| Date | Name | Thumbnail | Size | Description |
|---|---|---|---|---|
| 01:34, 20 April 2020 | Hot emboss r2r oled.jpg (file) |  |
30 KB | ''Left.'' The proposed structure of lenslets (small lenses) and OLED pixels to increase light emission. The hot embossed product is the PET foil that lies between the OLEDs and optics. ''Right.'' Image of a nickel shim master with the resulting hot embossed foil. |
| 01:33, 20 April 2020 | Hot emboss r2r y reactor.png (file) |  |
189 KB | A PMMA Y-microreactor before addition of connection ports made using hot embossing. |
| 22:24, 8 March 2020 | Hot emboss equipment.png (file) |  |
499 KB | |
| 19:16, 8 March 2020 | Master fab hot emboss.png (file) |  |
318 KB | Overview of soft lithography that also displays the hot embossing process and the connection to other fabrication processes. Obtained from Min Gu and Jing Wu's paper, " Microfluidic sensing: state of the art fabrication and detection techniques". |
| 19:13, 8 March 2020 | Hot emboss 1.png (file) |  |
29 KB | Hot embossing process simplified, b/w. |
