9/16/2015

Making Solutions:


Using the Magnetite hydrogel synthesis protocol to make diluted solutions of KNO3, KOH, Hemoglobin, and Cupric Acetate instead of FeSO4.


Cupric Acetate:

Mass (g) Measured: 1.4974

Molecular Weight g/mol: 199.65

Molar Concentration after diluted with 25mL H2O: 0.3 M


KOH:

Mass (g) Measured: 1.5396

Molecular Weight g/mol: 56.11

Molar Concentration after diluted with 25mL H2O: 1.0975 M


KNO3:

Mass (g) Measured: 2.2747

Molecular Weight g/mol: 101.1

Molar Concentration after diluted with 25mL H2O: 0.91315 M



9/23/2015

Making Hemoglobin and Stirring Solution with KNO3, KOH, Hemoglobin, and Cupric Acetate

Hemoglobin:


Mass (g) Measured: 0.0250

Molecular Weight g/mol: 64500

Molar Concentration after diluted with 25mL H2O: 1.5x10^-5


Using the Magnetite hydrogel synthesis protocol to make the 20mL solution.

-Heat water bath to 80°C

-Suspend solution in water bath so liquid is fully emerged.

-Mix solution with the IKA Eurostar 20 on 2500rpm for 1.5 hours.


Start time: 10:30am

End time: 12:00pm

Observations:

At 10 min: Solutions started changing from bright blue to dark blue.

At 20 min: Solutions is a very dark blue

At 40 min: Solution is fully black. Particles are starting to form above meniscus line.

AT 70 min: Solution continues to get darker.

-Put in centrifuge at 4000rpm, 3000BK, for 5 minutes


9/30/2015

-Two more 20 mL solutions where made. (Three total)

-Pictures were taken with microscope.

CoMicrogel-1 1 2.5X


CoMicrogel-1 1 2.5Xa


[Image:CoMicrogel-1 1 10Xa.bmp|CoMicrogel-1 1 10Xa]]


CoMicrogel-1 1 10Xb


CoMicrogel-1 1 20Xa


CoMicrogel-1 1 20Xb
