PDF of this page Lab 1: Eau that smell Note: This lab is also described in this Methods in Enzymology chapter Teacher Considerations This lab provides a valuable opportunity to teach microbiology techniques, population growth dynamics, molecular genetics and basic synthetic biology concepts in a meaningful, real world way. As can be seen in the discussion questions for the lab report, the analysis of the lab will provide the students with a chance to do meaningful error analysis and examine the difference between quantitative results and qualitative results. This lab offers two different protocols based on the time the teacher wishes to allow. Each of these protocols covers the same concepts but allows for different emphases. Protocol A--Condensed data collection: This is a shorter procedure for the students. This shorter protocol emphasizes data analysis over data collection. With this protocol the teacher can choose to have the students do the initial bacterial culturing if more microbial techniques are to be emphasized. Essentially, a day prior to any data collection, the large cultures are set up. Part of the starter culture is immediately removed and placed in the refrigerator. This serves as the lag phase sample. After 5-7 hours, a second sample is removed. This serves as the log phase sample. The last third of the culture should be allowed to grow overnight. This serves as the stationary phase sample. The samples can then be provided to the students the following class day, allowing the students to collect data in single lab period. Go to Protocol A for the detailed protocol. Protocol B--Growth curve data collection: This version provides a greater emphasis on collection of growth curve data. In this version, the students subculture from the overnight samples and then assess the banana smell and turbidity (population) of the subcultures every twenty minutes. To increase the number of data points, different classes can measure the same subcultures throughout the day. Alternatively, the subcultures can be refrigerated and warmed back to room temp for 30 minutes prior to the next data point collection. You should expect to collect data over three days to get data points from all phases of the growth curve. Go to Protocol B for the detailed protocol. Both procedures include instructions for using a spectrophotometer to measure the population growth. If a spectrophotometer is not available, the population can be easily measured using the McFarland Turbidity methodology. Instructions for this measurement are also included with each protocol. An introductory power point that can be adapted to either protocol can be found here. Also useful might be the MIT iGEM team presentation [video] and their ppt. Needed Materials Teacher Provides Luria Broth (LB) = 10 g Tryptone, 5 g Yeast Extract, 10 g NaCl, (1 liter) Sterile toothpicks (or innoculating loop and bunsen burner) Sterile tubes for growing liquid cultures of cells, (4) if testing all 4 strains Cuvettes to measure absorbances if spectrophotometer is not fitted for glass tubes 125 ml erlenmeyer flasks + stir bars, (4) if testing all 4 strains Stir plates, (4) if testing all 4 strains Pipetmen and tips (P1000, P200, P20) Pipets (5 ml) and bulbs Timers Sharpies Nitrile or Latex gloves Roller wheel at room temp or 37° for growing overnight cultures of bacteria (can use platform shaker instead) If available, vortex for mixing cells prior to additions If available, fume hood for measuring isoamyl alcohol (aka isopentyl alcohol) If turbidity standards are needed, will require 1.75 ml BaCl2 and ~80 ml 1% H2SO4 Kit Provides 4 strains (see table below) If shipped as stabs, store stabs at room temp If shipped on petri dishes, store plates as well as any liquid cultures you grow at room temp or 4° (= fridge) for longer times. Error creating thumbnail: Unable to save thumbnail to destination Chemicals Error creating thumbnail: Unable to save thumbnail to destination Room Temperature Concentrated Banana Extract to make Banana smell standards 4° (fridge) Ampicillin (100 mg). Can be added to 1 ml in H2O, filter sterilized and used at a 1:1000 dilution in LB. Alternatively, can add entire aliquot to 1 liter of LB and store LB + amp in the fridge. Chemical Hood 700 ul isoamyl alcohol, enough to prepare 1L of media for lab Sample Data Set Error creating thumbnail: Unable to save thumbnail to destination TEACHERS: Note that the original strain is supposed to smell like bananas only during stationary phase but we have found that it actually smells throughout the measurements we've made...perhaps because stationary phase activity starts earlier than we think. Similarly, we have seen the strain 1-2, which has the stationary phase promoter and the inverter, is more active throughout the growth curve and generates a stronger banana smell than strain 1-3, which has the log phase promoter. In our hands, Strain 1-3 is the most "log-phase specific" strain. Assessment Lab Report Rubric Download doc or pdf Lab Report ScoreSheet Download doc or pdf Survey To help us improve the labs, you can send the students here, where they can upload their data. "join a discussion" from the BioBuilder homepage email us: "info AT biobuilder DOT org" Thanks! Variations to try Can fruitflies be used to measure intensity of banana smell? What is effect on smells if growing the cells at different temperatures? If you are using the McFarland standard, would more precise or subtle standards be useful? Rather than telling the students which strain is which, can they identify the strains based on their smell patterns? Feedback We're always looking to hear back from you if you've thought about this unit, tried it, or stumbled across it and want to know more. Please email us through BioBuilder, info AT biobuilder DOT org. Navigation BioBuilding: Synthetic Biology for Teachers BioBuilding: Synthetic Biology for Teachers: Lab 1 BioBuilding: Synthetic Biology for Teachers: Lab 2 BioBuilding: Synthetic Biology for Teachers: Lab 3 BioBuilding: Synthetic Biology for Teachers: Lab 4 BioBuilding: Synthetic Biology for Teachers: Essay BioBuilding: Synthetic Biology for Teachers: Design Assignment BioBuilding: Synthetic Biology for Teachers: Glossary BioBuilding: Synthetic Biology for Teachers: Teacher's resource room BioBuilding: Synthetic Biology for Students [back to BioBuilder]
