Assay Team 5

Team 5 Notebook


Project 19395

Template:SBB10Project-19395

3/19/2010

Miniprep and mapping for tn5

  • Miniprep: Template:SBB-Protocols_Micro4
  • Mapping: Template:SBB-Protocols_Enz6
  • Ran gel with 10uL digest, 1uL 6X loading buffer.
  • EcoRI/BamHI digest yields fragments of size 2170 and 1446, which is approximately what is seen on the gel.
  • Image:Jl_031910.jpg
  • Ladder in first lane, then 4 clones sequentially.

3/17/2010

--Jennifer Lee 17:36, 17 March 2010 (EDT) Ala6 sequencing analysis and tn5: Analytical gel, digestion, ligation & transformation
Ala6 part:

  • Sequence for Clone plate A (Well E3) from 3/16/10 is a perfect read. See: Sequencing Log. Construct is pBjk2471-sbb34.

tn5 part:

3/15/2010

--Jennifer Lee 17:51, 15 March 2010 (EDT)
Analytical Gel for tn5....re-run PCR for tn5
tn5 part:

  • Run analytical gel (3uL PCR product, 7uL 1X loading buffer).
  • Image: sbb07_031510.jpg
  • The band above is again at ~500bp (PCR was re-run with the combined templates from PCR round 1 and oligos tn5001 and tn5002). After consultation with Mike and Will about possible mishaps, discovered the sbb07 construction file on the construction files page stated the second round of PCR should be done with oligos tn5001 and tn5004. This finding contradicts the construction file I had originally copy and pasted into my notebook (the corrected one) on Feb 10, 2010. Below is the newest version:
   Construction of Tn5 transposase basic part sbb07 {<tn5>}
    PCR tn5001/tn5003 on pRL27 (430 bp, gp = A)
    PCR tn5002/tn5004 on pRL27 (1056 bp, gp = B)
    ---------------------------------------------------
    PCR tn5001/tn5004 on A+B           (1456 bp, EcoRI/BamHI)
    Digest pBjk2741-Bca1144            (EcoRI/BamHI, 2170+910, L)
    Product is pBjk2741-tn5
    ---------------------------------------------------
   tn5001   Forward EcoRI and BglII for tn5
   CCATAgaattcATGagatctATAACTTCTGCTCTTCATCGTG
   tn5002   (F)Removing the Xho1 site in tn5
   CGTTCTCTTGCTaGAGGCCACCACATTCCG
   tn5003   (R)Removing the Xho1 site in tn5
   CGGAATGTGGTGGCCTCtAGCAAGAGAACG
   tn5004   Reverse BamHI and BglII removal for tn5
   CTGATggatccGATCTTGATCCCCTGCGCC
   Part: gatctATAACTTCTGCTCTTCATCGTGCGGCCGACTGGGCTAAATCTGTGTTCTCTTCGGCGGCGCTGGGTGATCCTCGCCGTACTGCCCGCTTGGTTAACGTCGCCGCCCAATTGGCAAAATATTCTGGTAAATCAATAACCATCTCATCAGAGGGTAGTAAAGCCGCCCAGGAAGGCGCTTACCGATTTATCCGCAATCCCAACGTTTCTGCCGAGGCGATCAGAAAGGCTGGCGCCATGCAAACAGTCAAGTTGGCTCAGGAGTTTCCCGAACTGCTGGCCATTGAGGACACCACCTCTTTGAGTTATCGCCACCAGGTCGCCGAAGAGCTTGGCAAGCTGGGCTCTATTCAGGATAAATCCCGCGGATGGTGGGTTCACTCCGTTCTCTTGCTaGAGGCCACCACATTCCGCACCGTAGGATTACTGCATCAGGAGTGGTGGATGCGCCCGGATGACCCTGCCGATGCGGATGAAAAGGAGAGTGGCAAATGGCTGGCAGCGGCCGCAACTAGCCGGTTACGCATGGGCAGCATGATGAGCAACGTGATTGCGGTCTGTGACCGCGAAGCCGATATTCATGCTTATCTGCAGGACAAACTGGCGCATAACGAGCGCTTCGTGGTGCGCTCCAAGCACCCACGCAAGGACGTAGAGTCTGGGTTGTATCTGTACGACCATCTGAAGAACCAACCGGAGTTGGGTGGCTATCAGATCAGCATTCCGCAAAAGGGCGTGGTGGATAAACGCGGTAAACGTAAAAATCGACCAGCCCGCAAGGCGAGCTTGAGCCTGCGCAGTGGGCGCATCACGCTAAAACAGGGGAATATCACGCTCAACGCGGTGCTGGCCGAGGAGATTAACCCGCCCAAGGGTGAGACCCCGTTGAAATGGTTGTTGCTGACCAGCGAACCGGTCGAGTCGCTAGCCCAAGCCTTGCGCGTCATCGACATTTATACCCATCGCTGGCGGATCGAGGAGTTCCATAAGGCATGGAAAACCGGAGCAGGAGCCGAGAGGCAACGCATGGAGGAGCCGGATAATCTGGAGCGGATGGTCTCGATCCTCTCGTTTGTTGCGGTCAGGCTGTTACAGCTCAGAGAAAGCTTCACGCCGCCGCAAGCACTCAGGGCGCAAGGGCTGCTAAAGGAAGCGGAACACGTAGAAAGCCAGTCCGCAGAAACGGTGCTGACCCCGGATGAATGTCAGCTACTGGGCTATCTGGACAAGGGAAAACGCAAGCGCAAAGAGAAAGCAGGTAGCTTGCAGTGGGCTTACATGGCGATAGCTAGACTGGGCGGTTTTATGGACAGCAAGCGAACCGGAATTGCCAGCTGGGGCGCCCTCTGGGAAGGTTGGGAAGCCCTGCAAAGTAAACTGGATGGCTTTCTTGCCGCCAAGGATCTGATGGCGCAGGGGATCAAGATCG

3/10/2010

--Jennifer Lee 18:01, 10 March 2010 (EST)
Miniprep for Ala6 & second round PCR for tn5
Ala6 part:

  • Macherey-Nagel miniprep protocol via Template:SBB-Protocols_Micro4. Used 2.5mL of each clone to generate a sizeable pellet.
  • Verify plasmid sizes via Template:SBB-Protocols_Enz6. Used Xho1, as the part is <250bp.Expected fragment sizes are ~700 and ~1700, which is what the gel shows (loaded 10uL digest, 1uL 6Xloading buffer).
  • Image:Jenicarolyn.jpg
  • Lanes 6-9 are sbb34 A-D respectively.

tn5 part:

3/8/2010

--Jennifer Lee 18:47, 8 March 2010 (EST)
Ligation & transformation for Ala6 & (failed) EcoRI/BamHI digestion for tn5
Set up digestion first and run ligation/transformation reaction within the hour-long digestion incubation.
Ala6 part:

tn5 part:

In lane 10 (sbb07) the fragment is approximately ~500 bp, which is not the size desired (should have been ~1450). Going back to the gel ran for 3/3/2010, it is evident the product was already wrong before the digest. Redoing the digest for sbb 07 and hopefully correcting this problem by re-diluting the oligos. It appears sbb07 1/3 were used instead of 1/2 for the second round of PCR.


3/3/2010

--Jennifer Lee 18:15, 3 March 2010 (EST)
*Ligation and transformation* for Ala6 part & analytical gel for tn5 part
Ala6 part:

  • Ligation reaction protocol for EIPCR products via Template:SBB-Protocols_Enz5. Ala6 part is already in pBjk2741 vector so no additional vector is added. Transformation by heat-shock into EColi protocol via Template:SBB-Protocols_Micro1. Cell strain JTK086, marked with double blue stripe.
    • Discovered the cell cocktail for ligation was done incorrectly; must re-start ligation/transformation reaction next week.*

tn5 part:

  • Run analytical gel for tn5 (3uL PCR product + 7uL loading buffer).
  • Gel Result:
  • Image:3-3-10-gel.png
  • Lanes 6/7: sbb07 1/2 DMSO & sbb07 1/2
  • Indicates successful SOEing reaction at new program, 2K45. Running zymo cleanup of sbb07 post PCR product (only the sbb07 1/2 reaction, stored the sbb07 1/2 DMSO reaction). Tube for sbb07 template is labelled "sbb07/temp post zymo for digest".


3/1/2010

--Jennifer Lee 17:28, 1 March 2010 (EST)
PCR attempt 2 for tn5 & zymo cleanup for Ala6; no time for ligation/transformation
Usual zymo cleanup on Ala6 prep gel product (with agarose, had added 600uL ADB buffer at the end of last lab for storage). Stored in BioE140L Box A as "sbb34 post zymo full template for ligation".


Re-ran 2 PCRs for sbb07 (tn5), once normally as a second attempt, another with 3.3uL DMSO substituted for 3.3uL of the total 24uL water. Running PCRs with 2K45 program, labelled PCR tubes as "sbb07 1/2" and "sbb07 1/2 DMSO". Protocol via Template:SBB-Protocols_PCR3.


2/24/2010

--Jennifer Lee 16:26, 24 February 2010 (EST)
Analytical gel for tn5 PCR2 & gel and BglII EIPCR digest for Ala6

  • Run analytical gel for second PCR round for tn5 (sbb07) (3uL PCR product + 7uL loading buffer). Named tn5,2 on analytical gel. Also run zymo cleanup via Template:SBB-Protocols_Zymo1 for the same sample. Store purified digest in "sbb07 post-zymo & PCR2" tube, placed in BiOE140L Box A.


  • Analytical gel result for tn5:
  • Image:JC022410gelprel.jpg.
  • Expected a 1456bp length fragment which did not appear in Lane 7. Considering a different protocol for SOEing.


Tubes of DNA now labelled: (format: LID:SIDE)

  • sbb34: sbb34 post zymo cleanup (ready for digest)
  • sbb07 tn5: tn5 prep for PCR2 templates combined (before running PCR2, the two templates from PCR1 combined)
  • sbb07: post zymo& PCR2 (after running PCR2, ready for digest)


  • BglII EIPCR product digest of Ala6 (sbb34) via Template:SBB-Protocols_Enz3.
  • Incubated 2-3pm. Tube is labelled "sbb34 digest rxn, Ala6 digest". Ran gel with 10uL digestion product and 1uL loading buffer. Cut out band in gel image below, labelled tube "sbb34 post digest: cut Ala6 post digest 2219bp" --> should be labelled 2203 bp.
  • Gel result for Ala6 (sbb34-band 7):
  • Image:DDT_02_22_10.jpg


2/22/2010

--Jennifer Lee 16:14, 22 February 2010 (EST)
Last week: PCR
Cloned DNA sample using PCR protocol available Template:SBB-Protocols_PCR2


This week: Analytical & Preparative Gels for tn5 and Ala6; Ala6 Zymo Cleanup; set-up round 2 PCR for tn5
tn5 part:

  • Preparative gel for SOEing reaction (tn5): 6uL PCR product + 4uL loading buffer
  • Tubes for gel labelled sbb071/3 and sbb072/4.
  • Gel Result: Bands 8 and 9 are sbb071/3 and sbb072/4/ PCR reactions, respectively.
  • Image:Zgel_JHL_2_22_10.png

Ala6 part:

  • Analytical gel for Ala6: 3uL PCR product + 7uL loading buffer
  • Tube for gel labelled sbb34


Ran Template:SBB-Protocols_Zymo1 for Ala6 part. Stored in BioE140L Box A.
Ran Template:SBB-Protocols_Zymo3 for Tn5. (Melted prep gel). Eluted DNA in 50uL water, stored DNA template in "tn5 PCR2 template combined" tube (lid says "sbb07, tn5"); stored in BioE140L Box A. Run new PCR for "Tn05 #2" according to Template:SBB-Protocols_PCR2. Stored round 1 PCR products in BioE140L Box A.


Procedure flow: PCR --> Analytical Gel --> Zymo cleanup --> Digest --> Gel purification --> Ligation --> Transformation


2/10/2010

--Jennifer Lee 18:03, 10 February 2010 (EST)
Updated Construction files

Construction of Ala6 basic part sbb34
EIPCR Ala6-F/tn0002R on pBjk2741-Bca1144   (2219 bp, BglII)
Product is pBjk2741-sbb34   {<Ala6>}
----
Ala6-F  EIPCR construction of Alanine-6 part
CCATAagatctgcTgcCgcagcagcagcaGGATCCtaaCTCGCTCCTCagg
tn0002R	Reverse BglII oligo for Tn5 EIPCR
CCAATAGATCTcatgaattcCACTTCAG
Part:  gatctgcTgcCgcagcagcagcaG


   Construction of Tn5 transposase basic part sbb07 {<tn5>}
    PCR tn5001/tn5003 on pRL27 (430 bp, gp = A)
    PCR tn5004/tn5002 on pRL27 (1056 bp, gp = B)
    ---------------------------------------------------
    PCR tn5001/tn5002 on A+B           (1456 bp, EcoRI/BamHI)
    Digest pBjk2741-Bca1144            (EcoRI/BamHI, 2170+910, L)
    Product is pBjk2741-tn5
    ---------------------------------------------------
    tn5001   Forward EcoRI and BglII for tn5
   CCATAgaattcATGagatctATAACTTCTGCTCTTCATCGTG
    tn5004   (F)Removing the Xho1 site in tn5
   CGTTCTCTTGCTaGAGGCCACCACATTCCG
    tn5003   (R)Removing the Xho1 site in tn5
   CGGAATGTGGTGGCCTCtAGCAAGAGAACG
    tn5002   Reverse BamHI and BglII removal for tn5
   CTGATggatccGATCTTGATCCCCTGCGCC
   Part: gatctATAACTTCTGCTCTTCATCGTGCGGCCGACTGGGCTAAATCTGTGTTCTCTTCGGCGGCGCTGGGTGATCCTCGCCGTACTGCCCGCTTGGTTAACGTCGCCGCCCAATTGGCAAAATATTCTGGTAAATCAATAACCATCTCATCAGAGGGTAGTAAAGCCGCCCAGGAAGGCGCTTACCGATTTATCCGCAATCCCAACGTTTCTGCCGAGGCGATCAGAAAGGCTGGCGCCATGCAAACAGTCAAGTTGGCTCAGGAGTTTCCCGAACTGCTGGCCATTGAGGACACCACCTCTTTGAGTTATCGCCACCAGGTCGCCGAAGAGCTTGGCAAGCTGGGCTCTATTCAGGATAAATCCCGCGGATGGTGGGTTCACTCCGTTCTCTTGCTaGAGGCCACCACATTCCGCACCGTAGGATTACTGCATCAGGAGTGGTGGATGCGCCCGGATGACCCTGCCGATGCGGATGAAAAGGAGAGTGGCAAATGGCTGGCAGCGGCCGCAACTAGCCGGTTACGCATGGGCAGCATGATGAGCAACGTGATTGCGGTCTGTGACCGCGAAGCCGATATTCATGCTTATCTGCAGGACAAACTGGCGCATAACGAGCGCTTCGTGGTGCGCTCCAAGCACCCACGCAAGGACGTAGAGTCTGGGTTGTATCTGTACGACCATCTGAAGAACCAACCGGAGTTGGGTGGCTATCAGATCAGCATTCCGCAAAAGGGCGTGGTGGATAAACGCGGTAAACGTAAAAATCGACCAGCCCGCAAGGCGAGCTTGAGCCTGCGCAGTGGGCGCATCACGCTAAAACAGGGGAATATCACGCTCAACGCGGTGCTGGCCGAGGAGATTAACCCGCCCAAGGGTGAGACCCCGTTGAAATGGTTGTTGCTGACCAGCGAACCGGTCGAGTCGCTAGCCCAAGCCTTGCGCGTCATCGACATTTATACCCATCGCTGGCGGATCGAGGAGTTCCATAAGGCATGGAAAACCGGAGCAGGAGCCGAGAGGCAACGCATGGAGGAGCCGGATAATCTGGAGCGGATGGTCTCGATCCTCTCGTTTGTTGCGGTCAGGCTGTTACAGCTCAGAGAAAGCTTCACGCCGCCGCAAGCACTCAGGGCGCAAGGGCTGCTAAAGGAAGCGGAACACGTAGAAAGCCAGTCCGCAGAAACGGTGCTGACCCCGGATGAATGTCAGCTACTGGGCTATCTGGACAAGGGAAAACGCAAGCGCAAAGAGAAAGCAGGTAGCTTGCAGTGGGCTTACATGGCGATAGCTAGACTGGGCGGTTTTATGGACAGCAAGCGAACCGGAATTGCCAGCTGGGGCGCCCTCTGGGAAGGTTGGGAAGCCCTGCAAAGTAAACTGGATGGCTTTCTTGCCGCCAAGGATCTGATGGCGCAGGGGATCAAGATCG


2/9/2010

--Jennifer Lee 00:45, 9 February 2010 (EST)

Completed project parts:

Construction of Tn5 transposase basic part sbb07 {<tn5>}
PCR tn5001/tn5003 on pRL27 (438 bp, gp = A)
PCR tn5004/tn5002 on pRL27 (1069 bp, gp = B)
---------------------------------------------------
PCR tn5001/tn5002 on A+B           (1462 bp, EcoRI/BamHI)
Digest pBjk2741-Bca1144            (EcoRI/BamHI, 2170+910, L)
Product is pBjk2741-tn5
---------------------------------------------------
tn5001   Forward EcoRI and BglII for tn5 	     CCATAgaattcATGagatctATGATAACTTCTGCTCTTCATCGTGC
tn5004   (F)Removing the Xho1 site in tn5   	     GGGTTCACTCCGTTCTCTTGCTCGAAG
tn5003   (R)Removing the Xho1 site in tn5   	     CGGTGCGGAATGTGGTGGCTTCGAG
tn5002   Reverse BamHI and BglII removal for tn5    CTGATggatccTCGGATCTTGATCCCCTGCGCC


Construction of Ala6 basic part sbb34
EIPCR Ala6-F/ca2741R on pBjk2741-Bca1144   (2203 bp, BglII)
Product is pBjk2741-Ala6    {<Ala6>}
----
Ala6-F  EIPCR construction of Alanine-6 part
		CCATAagatctgcagcagcagcagcagcaGGATCCtaaCTCGCTCCTCagg
jl2741R Reverse BglII oligo for Ala6 EIPCR on pBjk2741-Bca1144
		CTGAAGTGgaattcatgAGATCTATTGG
