This is the autoclave in the lab. From top to bottom everything is:
- Pressure Gauge
- Green Power Switch
Knobs on the left
- Timer Knob (measured in mins.)
- Temperature Knob (°C and °F)
Lights on the right
- Power (green)
- Dry (orange)
- Heat (orange)
- Multi Purpose Valve
